Product Advantage:
1. Efficiency increased by 2-10 times.
2. High-quality welding with smooth weld seams, no need for subsequent grinding.
3. Low cost, saving at least 2 welders.
4. 360 degree flexible movement welder with no experience can do a good job.
5. Welding mode with or without wire function as cutter for thin steel.
Product Configuration
No. | Name | quantity | Specification | Remark |
1 | Fiber laser | 1 set | 900W/1200W/1500W | XQL |
2 | Handheld welding head | 1 | Wobble | XQL |
3 | Optical fiber cable length | 1 | 10 m | XQL |
4 | Control system | 1 set | Touch screen | XQL |
5 | Electrical control | 1 set | Automatic air blow | XQL |
6 | Wire feeder | 1 set | Automatic wire feeding | / |
0.8, 1.0, 1.2, 1.4,1.6(mm) | / | |||
7 | Protective lens | 5 pieces | D18*T2 | / |
8 | Nozzles | 1 set | 8 models, one each | / |
9 | Machine tool machinery platform and accessories | 1 set | One-piece sheet metal | / |
Technical Parameter
Index | Parameter |
Machine model | XQL-H1500F/H2000F/H3000F |
Laser power | 900W/1200W/1500W |
Peak power | 1500W/2000W/2500W |
Power required | AC 220V 50Hz |
Physical dimension | 675*370*600(mm) |
Weight | 45kg |
Cooling method | Air cooling |
Laser source | Fiber laser |
Laser wavelength | 1080±5nm |
Fiber optical length | Standard 10 meters, support 15 meters |
Laser energy stability | <2% |
Operating temperature | -20-60℃ |
Storage temperature | -30-70℃ |
Work patterns | Continuous/Modulation |
Wobble frequency | 0-300(Hz) |
Air humidity | 10-90% |
Auxiliary gas | Argon/Nitrogen, Water-Free & Oil-Free air |
Welding Parameter
Items | 900W | 1200W | 1500W |
Stainless steel | 4 mm | 5mm | 6 mm |
Carbon steel | 4 mm | 5 mm | 6 mm |
Galvanized sheet | 4 mm | 5 mm | 6 mm |
Aluminum | 3 mm | 4 mm | 5 mm |
Weld width | ≤5 mm | ||
Remark | Based on the actual welding effect test, this test data is for reference only. |
