Machine Features:
• Portable & Flexible Operation
Compact and easy to handle, ideal for on-site or complex welding environments where mobility is required.
• High-Precision Laser Welding
Provides fine, clean, and accurate welding results with excellent beam quality and minimal heat deformation.
• Multi-Function Capability
Supports welding, cutting, and light cleaning functions for versatile metal processing needs.
• Clean & Non-Destructive Welding Process
Non-contact laser welding leaves no mechanical stress, no burn marks, and ensures smooth, aesthetically clean welds.
• Stable Dual-Cooling System
Uses dual-temperature water cooling to maintain consistent laser performance and extended machine lifespan.
• Wide Material Compatibility
Suitable for stainless steel, carbon steel, galvanized steel, aluminum, and other metal plates up to 8mm.
• Repeatable & Consistent Results
Preset laser parameters ensure uniform welding quality and high production efficiency.
Products Specification:
| Item | Details |
| Model | LW Series Handheld Metal Fiber Laser Welding Machine |
| Power Options | 1500W / 2000W / 3000W |
| Fiber Length | 7m / 10m (standard), 15m customizable |
| Laser Wavelength | 1070–1080nm |
| Welding Speed | 0–120mm/s |
| Chiller | Dual-temperature & dual-control constant temperature water cooling system |
| Working Environment | 5–40°C, humidity <70%, non-condensing |
| Applicable Plate Thickness | 0.6–8mm |
| Maximum Power Consumption | < 5kW |
| Working Voltage | 220V / 380V, 50Hz |
| Machine Weight | 120–160kg |
