Product Features:
1. Adopting the latest pneumatic lightweight design, it can complete the cutting stroke without shear stress in one go, especially suitable for cutting precision SMD or thin plates;
2. Bow waves (BOWWAVES) and microcracks (MICROCRACK) generated during plate splitting without a circular blade, using a wedge-shaped tool for linear plate splitting,
The shear stress is minimized, allowing sensitive SMD components, even capacitors, to remain unaffected and minimizing potential quality risks of the product;
3. The cutting stroke is less than 1MM, without any operational safety concerns. The cutting tool is made of high-speed steel precision grinding, which can be reused for grinding;
4. The cutting rate is 1 second/1 division, controlled by a foot pedal pneumatic switch;
5. The cutting blade group is passively activated, which can safely grasp the cutting line and position; Low cutting stress, less prone to cracking;
6. Non roller (straight blade) cutting, no dust phenomenon, no motor drive, no carbon powder pollution;
7. Non friction cutting, no tool metal residue;
8. Can design/customize knife specifications according to customer products;
9. Can be customized for longer lengths.
Product Parameter:
| Splitting length (mm) | 330MM or 500MM (customizable according to customer requirements) |
| Working air pressure (MPa) | 0.50-0.70 (dry air source) |
| Plate thickness (mm) | 0.6~~3.5 |
| Machine weight (kg) | 130 |
| Operating voltage (V) | 220 VAC |
| Overall dimensions (mm) | 750×500×600 |
